Transzformációk


Transzformációs mátrix PS-ben:



Homogén koordinátákkal:



Ahol T a transzformációs mátrix:



PS-ben:



A grafikus állapot tartalmazza a Kurrens Trancformációs Mátrixot (CMT), amely megadja a felhsználói térből az eszköztérbe való transzformációt.

Transzformációk:

Eltolás:



Forgatás:



Nagyítás:



Ált:



Pl.:

[ 72 0 0 72 0 0 ] concat
72 72 scale


Automatikus ciklus:

Tömb proc forall -

A tömb minden elemére végrehajtja a proc-ot ( 0-ás indexüvel kezdve )

pl.:
  0 [13 29 3 -8 21 ] {add} forall 58


Példa:



%Variables

/LM 72 def
/RM 216 def
/ypos 720 def
/lineheight 11 def

%Procedures

/crlf
{ ypos lineheight sub
/ypos exch def
LM ypos moveto } def

/prtstr
{ dup stringwidth pop
currentpoint pop
add RM gt
{crlf} if
show } def

/format
{ { prtstr () show } forall
} def

%Main Program

/Times-Italic findfont 10 scalefont setfont
LM ypos moveto

%Text array:

[(Concience)(is)(the)(inner)(voice)
(that)(warns)(us)(somebody)(may)(be)
(looking)(- Mencken ) ]
format

showpage


Aload:

tömb aload tömb0...tömb(n-1) tömb
a tömb n elemét és a tömböt a verembe rakja

pl.:
[23 (ab)-6] aload 23 (ab)-6 [23(ab)-6]


Astore:

x1 ... x(n-1) tömb astore tömb
x1 ... x( n-1) -et elrakja a tömb-be.

pl.:
(a)(bcd)(ef) 3 array astore [(a)(bcd)(ef)]

Példa:



%Variables & procedures


/LM 72 def

/newline
{ currentpoint 10 sub
exch pop LM exch
moveto } def

/PrintSample
{ aload pop
findfont 8 scalefont setfont
show newline } def

/Fontlist [
[(The five boxing wizards jump quickly.)
/Helvetica]
[(The five boxing wizards jump quickly.)
/Times-Roman]
[(The five boxing wizards jump quickly.)
/Symbol]
] def

%Begin Program

LM 600 moveto
FontList {Printsample) forall
showpage
